5.2.3 FREEZED DATA

KEIHIN

1.ECU ID

2.DATA STREAM

3.FREEZED DATA

4.TROUBLE CODE

5.ERASE TB CODE

7.CO ADAPTION

▓FREEZED DATA (KEIHIN)

This function will show relevant data when the trouble takes

place.

(01/01) DATA STREAM

→FAULT NO.---------

FAULT CODE-------------

Engine SPD----------RPM

Engine temp----------V (85 ~ 115'C)

Engine temp----------V (0.1~4.8V)

TPS position----------V (Idle :<1.5%)

MAP---------V (Idle :32~38Kpa)

Intake Air------------V

O2 SENSOR-------------mV (Idle :0.58~0.62)

BATT. VOLT------------V (Idle :>12V)

<UP>prev<DOWN>next<Ent>fixed<F4>waveform

<EXIT>exit<LEFT>PgUp<RIGHT>PgDn,<F1>Help
