KSR IDS-101 - Page 6

2
Fig 2.1 Main controller picture
Main parts Descriptions:
U-Key : Move cursor to up, or in some functions ( i.e. Activation ), increase
value.
D-Key : Move cursor to down, or in some functions ( i.e. Activation ) , decrease
F2-KEY
Cf card socket
ESC-KEY
F1-KEY
LCD Screen
R-KEY
ENTER-KEY
L-KEY
D-KEY
U-KEY
Extension connector
port
