26
▓ECU PIN ASSIGN
(KEIHIN)
1 10 18
19 36
1: IGP [R/Y] B+
2:
3: CRK-P [G/W] Crankshaft pos. sensor+
4:
5: TH [W/Br] Throttle angle(A/D)
6: PM [B/R] Manifold press. SNSR I/P(A/D)
7: HEGO [Pink/B] O2 sensor(A/D)
8: LG [G] shield GND
