▓Press [left]/[right] key to
change page.
▓Fix ( single data value)
▓Use [up]/[down] keys to
move the arrow point (→)
of left side, after pointing
to the item wanted to fix,
Press [Enter] button,。
（02-03） DATA STREAM
Engine temp---105'C(85~115'C)
BARO------102.5Kpa(>98Kpa)
Intake Air----33'C
2nd AIR VALVE--------ON(Idle ON)
INJECT TIME------1.65mS(Idle 1~3mS)
IGN. ANGLE-------13'(Idle 12~14')
STEP MOTOR--------STABLE
CRANKSHAFT---------CW(Idle CW)
TEST TERMINAL---------SHORT(Idle
OPEN)
IDLE SET----1660RPM(1650RPM)
（01-03） DATA STREAM
→Engine SPD----------RPM
Intake Air-----------'C
Intake Air---------V
Engine temp---------'C
Engine temp-------V
BARO-----------Kpa
BARO--------V
TPS-------------%
TPS---------V
CO METER----------------V
