47
（02-03） DATA STREAM
Engine SPD--1733RPM(Idle
1550~1750)
Engine temp------106'C(150~135'C)
BATT. VOLT---------14V( > 12V)
SNSR POWER---4.99V(5+-0.5V)
INJECT TIME---------1.65mS
IGN. ANGLE---------6.37'
IGN.CHARGE-----2.17mS
TPS INIT.---0.72V
IDLE SET----1660RPM(1650RPM)
CO ADJUST----0
▓DATA STREAM Page:（SENGTON）
Engine SPD--1733RPM(Idle
1550~1750)
Intake Air---------36'C(25~40'C)
Intake Air-----2.85V
Engine temp------106'C(115~135'C)
Engine temp---1.23V
BARO----------102.5Kpa
BARO-----3.98V
TPS----------0%
TPS----------0.72V
CO METER-----0.0V(Idle 0.5~2.5V)
Engine SPD--1733RPM(Idle
1550~1750)
Engine temp------106'C(115~135'C)
BARO---------102.5Kpa
RUN TIME----22Hr
‘C METER O/P--1.7%
BYPASS OPEN------53.3'(40~100')
FUEL PUMP----ON
MANUAL TPI----INACT
C.ACC TIME----0.6 Hr
C.ACC RESET--0.0 Hr
▓Press [left]/[right] key to
change page.
