KTM 1090 ADVENTURE 2017 User Manual

8 ERGONOMICS 68
8.7 Adjusting the footrests
Info
The operations on the footrest brackets are the same for the left and right sides.
F00646-10
–
Remove screw
1
.
The foot brake lever swings up to the stop.
M00882-10
–
Remove cotter pin
2
with washer
3
.
–
Carefully remove the pin
4
of the rider footrest.
Info
The spring is under high tension and can pop out when the pin is removed.
–
Take off the rider footrest
5
with the spring.

KTM 1090 ADVENTURE 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1050 cc
Torque	109 Nm @ 6500 rpm
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	850 mm
Dry Weight	205 kg
Front Suspension	WP USD Ø 48 mm
Fuel System	Electronic Fuel Injection
Bore x Stroke	103 mm x 63 mm
Compression Ratio	13.0:1
Starter	Electric starter
Power	92 kW (125 hp) @ 8500 rpm
Rear Suspension	WP monoshock
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9M+ two-channel ABS
Cooling	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Tire	120/70 R19
Rear Tire	150/70 R17
