22 TECHNICAL DATA
238
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ABS hose clamp M6 7 Nm (5.2 lbf ft)
Screw, ABS module M6 10 Nm (7.4 lbf ft)
Screw, ABS module retaining
bracket on frame
M6 7 Nm (5.2 lbf ft)
Screw, air filter box M6 6 Nm (4.4 lbf ft)
Screw, brake fluid reservoir for rear
brake
M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, brake hose clamp M6 7 Nm (5.2 lbf ft)
Screw, chain sliding guard M6 7 Nm (5.2 lbf ft)
Screw, combination instrument M6 7 Nm (5.2 lbf ft)
Screw, compensating tank M6 5 Nm (3.7 lbf ft)
Screw, damper block M6 8 Nm (5.9 lbf ft)
Screw, engine sprocket cover M6 8 Nm (5.9 lbf ft)
Screw, foot brake cylinder M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, front fender M6 7 Nm (5.2 lbf ft)
Screw, front seat fixing M6 6 Nm (4.4 lbf ft)
Screw, front spoiler M6x12 9 Nm (6.6 lbf ft)
Screw, front spoiler lower part M6x14 9 Nm (6.6 lbf ft)
Screw, fuel pump M6 10 Nm (7.4 lbf ft)
