22.2 Engine tightening torques
Oil nozzle M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, crankshaft speed sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, gear sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket, stator
cable
M5 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, stator M5 8 Nm (5.9 lbf ft)
Loctite
®
243™
Cylinder head screw M6 12 Nm (8.9 lbf ft)
Nut, water pump impeller M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Oil nozzle M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw plug, water pump drain hole M6 10 Nm (7.4 lbf ft)
Screw, alternator cover M6 12 Nm (8.9 lbf ft)
Screw, bearing retainer M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, camshaft bearing support M6 10 Nm (7.4 lbf ft)
Screw, camshaft, decompression
shaft
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain securing guide M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch cable retaining
bracket
M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch cover M6 12 Nm (8.9 lbf ft)
Screw, clutch spring M6 10 Nm (7.4 lbf ft)
Screw, engine case M6x35 12 Nm (8.9 lbf ft)
Screw, engine case M6x75 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, engine vent plate M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, freewheel gear retaining
bracket
M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, lock washer, engine
sprocket
M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, locking lever M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft)
Screw, oil pump M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, retaining bracket M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, retaining bracket, radial
shaft seal ring, clutch cover
M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
