KTM 50 SX Mini Setup Instructions

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 50 SX Mini Specifications

General

Engine Type	Single-cylinder, 2-stroke
Cooling System	Liquid cooled
Transmission	Automatic
Starter	Kickstarter
Rear Suspension	WP XACT Monoshock
Front Brake	Disc brake
Rear Brake	Disc brake
Weight	40 kg
Bore x Stroke	39.5 mm x 40 mm
Weight (without fuel)	40 kg
Front Brake Type	Hydraulic disc brake
Rear Brake Type	Hydraulic disc brake
Frame	Central tube frame, chrome molybdenum steel
Front Suspension	WP XACT 35 USD, Ø 35 mm
