MAINTENANCE ON CHASSIS AND ENGINE 41
Fork offset
The fork offset has an impact on the handling of the vehicle.
The fork offset can optionally be adjusted.
Fork offset is defined as the slanted position of the swivel axis in the direction of the longitudinal axis of the vehicle in relation to a
vertical line to the driving surface.
When both sleeves are installed in front of the A-arms, the fork offset increases. This enhances driving stability on fast raceways.
When both bushings are installed behind the A-arms, the fork offset decreases. This improves handling in bends.
Upon delivery one bushing is installed in front of the A-arm and one behind it.
Adjusting the fork offsetbx
Info
The left and right fork offset should have the same settings.
The operations are the same on the left and right.
ದ Jack up the vehicle. ( P. 31)
600126-11
ದ Remove screwsb with bushingsb.
ದ Check parts for damage and wear. Replace damaged or worn parts.
ದ Place the A-arm with the bushingsb
in the desired position. Mount and tighten
screwsb
.
Specification
Screw, A-arm top M10x52 45bNm
(33.2blbfbft)
ದ Remove the vehicle from the work stand. ( P. 31)
Toe width of rear axle
100101-10
The toe widthb can be adjusted by installed the spacing sleeve in various ways.
Difference between nar-
row/wide toe
76bmm (2.99bin)
Adjusting the toe width of rear axlebx
Warning
Danger of accidentsಘChanges to the chassis can strongly influence how the vehicle handles.
ದ After making changes, always ride slowly to allow yourself to respond to vehicle handling.
ದ Engage 1st gear.
100102-10
ದ Loosen nutsb of the wheel hubs on both sides.
ದ Jack up the vehicle. ( P. 31)
ದ Remove the nutsb
on both sides and take all parts off of the rear axle.
ದ Check parts for damage and wear. Replace damaged or worn parts.
Info
The left and right toe width should have the same settings.
