KTM 85 SX - Page 16

ENGLISH
15
PERIODIC MAINTENANCE SCHEDULE
»
85/105 SX/XC 2008
IMPORTANT SERVICE WORK THAT MUST BE PERFORMED BY AN AUTHORIZED KTM WORKSHOP
UNDER A SEPARATE ORDER
Every 20 hours Every 40 hours At least once a year Every 2 years
Clean and adjust carburetor
z
Check the reed-type intake valve for wear
z z
Check the wear on the clutch disks and length of the clutch springs
z z
Check the cylinder and piston for wear
z z
Check function of exhaust control
z z
Check piston pin bearing
z
Replace the crankshaft main bearings
z
Replace the conrod bearings
z
Check the entire transmission, the shift mechanism and bearings
z
Complete maintenance of fork
z z
Complete maintenance of shock absorber
z
Clean and grease steering head bearings and gasket elements
z
Replace the sealing cup for the foot brake cylinder
z z
Replace the glass-fiber yarn filling in the silencer
z z
Treat electric contacts and switches with contact grease
z
Change break fluid
z z z
Change hydraulic clutch fluid
z
Change the hydraulic clutch oil
85/105 SX/XC 2008
IMPORTANT CHECKS AND MAINTENANCE TO BE CARRIED OUT BY THE RIDER OR THE MECHANIC
before each start
after every cleaning
for cross country use
once a year
Check gear box oil level
z
Check brake fluid level
z
Check brake pads for wear
z
Lubricate and adjust cables and nipples
z
Bleed fork legs regulary
z
Remove and clean dust bellows regularly
z
Clean and lubricate chain, check tension and adjust if necessary
z z
Clean air filter and filter box
z z
Check tires for pressure and wear
z
Check cooling liquid level
z
Check fuel lines for leaks
z
Empty and clean float chamber
z z
Remove, clean and oil the throttle slide
z
Check all control elements for smooth operation
z
Check brake performance
z z
Treat blank metal parts (with the exception of brake and exhaust systems)
z
with wax-based anti corrosion agent
Check tightness of screws, nuts and hose clamps regularly
z
Note: If the inspection establishes that permissible tolerances are exceeded, the respective components must be replaced.
