KTM 890 ADVENTURE R 2021 User Manual

2 SETUP
8
F02135-10
(EU)
–
Mount reflector
8
with rubber bushings
9
and tension
washers
bk
on the license plate holder
bl
.
– Position the license plate bracket on the license plate sup-
port.
–
Mount and tighten screws
bm
.
Guideline
Screw, license
plate holder
M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
– Carefully loosen and remove the rear tension belt.
Info
An assistant prevents the motorcycle from falling over.
– Carefully loosen and remove the tension belts around the lower
triple clamp.
The vehicle is released at the front.
– Together with an assistant, take the vehicle off the pallet.
F02136-10
–
Mount rubber spacers
bn
on the retaining bracket
bo
.
–
Position retaining bracket
bo
on the engine guard.
–
Mount and tighten screws
bp
.
Guideline
Screw, engine
guard retaining
bracket
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™

KTM 890 ADVENTURE R 2021 Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Seat Height	880 mm (34.6 in)
Rear Suspension	WP XPLOR PDS shock absorber
Compression Ratio	13.5:1
Final Drive	Chain
Power	77 kW (105 hp)
Torque	100 Nm
Fuel Tank Capacity	20 liters
Dry Weight	196 kg
Front Suspension	WP XPLOR USD
Front Brake	2 x 320 mm disc, 4-piston radial fixed caliper
Rear Brake	2-piston caliper, brake disc Ø 260 mm
ABS	Bosch 9.1 MP (Cornering ABS and offroad mode)
Frame	Chromium-Molybdenum-Steel frame using the engine as a stressed element, powder coated
Wheelbase	1, 528 mm
