2 SETUP
6
F02131-10
– Position the brake assembly on the handlebar.
– Position brake assembly clamp on the handlebar.
The holding lug of the clamp engages in the combination
switch.
–
Mount and tighten screws
1
.
Guideline
Screw, brake assem-
bly
M6 5 Nm (3.7 lbf ft)
– Tighten all the screws on the controls on the right half of the
handlebar.
Guideline
Screw for throttle
grip
M5 3.5 Nm
(2.58 lbf ft)
Screw, combination
switch, right
M5 5 Nm (3.7 lbf ft)
Info
Pay attention to the markings on the handlebar.
Make sure the cables and wiring are positioned cor-
rectly.
– Tie the cables and wires together with the rubber straps sup-
plied.
– Check the throttle grip for smooth operation.
F02132-10
– Position the clutch assembly on the handlebar.
Info
Pay attention to the markings on the handlebar.
– Position the clutch assembly clamp on the handlebar.
–
Mount and tighten screws
2
.
Guideline
Screw, clutch assem-
bly
M6 5 Nm (3.7 lbf ft)
– Tighten all the screws on the controls on the left half of the
handlebar.
Guideline
Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)
Screw, combination
switch, left
M5 2 Nm (1.5 lbf ft)
Info
Pay attention to the markings on the handlebar.
Make sure the cables and wiring are positioned cor-
rectly.
– Tie the cables and wires together with the rubber straps sup-
plied.

KTM 890 ADVENTURE R 2021 Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Seat Height	880 mm (34.6 in)
Rear Suspension	WP XPLOR PDS shock absorber
Compression Ratio	13.5:1
Final Drive	Chain
Power	77 kW (105 hp)
Torque	100 Nm
Fuel Tank Capacity	20 liters
Dry Weight	196 kg
Front Suspension	WP XPLOR USD
Front Brake	2 x 320 mm disc, 4-piston radial fixed caliper
Rear Brake	2-piston caliper, brake disc Ø 260 mm
ABS	Bosch 9.1 MP (Cornering ABS and offroad mode)
Frame	Chromium-Molybdenum-Steel frame using the engine as a stressed element, powder coated
Wheelbase	1, 528 mm
