SETUP 2
9
F02598-01
(XC‑F US FACTORY EDITION)
– Mount the Factory‑Start.
Info
Read the accompanying KTM PowerParts instruc-
tions.
F02583-10
(XC‑F US FACTORY EDITION)
– Mount the brake disc guard.
Info
Read the accompanying KTM PowerParts instruc-
tions.
Align the brake disc guard so that the distances are
the same size.
– Install the front wheel. ( p. 15)
D00674-10
Left and right footrest (All SX‑F models)
– Position the new footrest and pin.
Info
Only insert the pin to the extent that the spring can
still be mounted.
K00621-12
– Position spring as shown.
Spring
B
engages in area
C
.
