GENERAL
B1830,B2230,B2530,B3030, WSM
G-68
(1) Front Wheels
Front wheel tread can not be adjusted.
• Do not turn front discs to obtain wider tread. In setting up the front wheels, make sure that the inflation
valve stem of the tires face outward.
[B1830, B2230 and B2530]
[B3030]
9Y1210003GEG0075US0
Models B1830 B2230 B2530 B1830 / B2230 B2530
Tire 6-12B Farm 6-12 Farm 6.00-12 Farm 22 × 8.50 - 12 Turf 24 × 8.50 - 12 Turf
Tread
835 mm (32.9 in.) 870 mm (34.3 in.)
Tire 7-12 Farm 24 × 8.50 - 12 Turf
Tread
935 mm (36.8 in.) 970 mm (38.2 in.)
Tightening torque Front wheel
149.2 to 179.0 N·m
15.2 to 18.3 kgf·m
110 to 132 lbf·ft
(1) Wheel Mounting Screw
