Kubota B3350SU - Page 24

4 SPECIFICATIONS
NOTE: * SAE J1995 The company reserves the right to change the specifications without notice.
Hydraulic
unit
Hydraulic control system Position control Quarter inching valve
Pump capacity
L / min
(gals / min)
33.1 (8.7)
3-point hitch SAE Category 1
Max. lift force
At lift points kg (lbs.) 970 (2139)
24 in.behind
lift point
kg (lbs.) 760 (1676)
PTO
Rear-PTO SAE 1-3/8, 6 splines
PTO / Engine speed rpm
1 speed
540 / 2398
Mid-PTO USA No. 5 (KUBOTA 10-tooth) involute spline -
PTO / Engine speed rpm
1 speed
2500 / 2500
-
Model B2650HSD B3350HSD B3350SUHSD
