Kubota BX2670 Workshop Manual

FRONT AXLE
BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM
3-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1210855FBS0003US0
Item N·m kgf·m lbf·ft
Front wheel mounting screw 149 to 179 15.2 to 18.3 110 to 132
Tie-rod slotted nut 18 to 34 1.8 to 3.5 13 to 25
Power steering cylinder mounting screw 48 to 55 4.9 to 5.7 36 to 41
Power steering hose 24 to 27 2.4 to 2.8 18 to 20
Bevel gear case mounting screw (M10) 48 to 55 4.9 to 5.7 36 to 41
Bevel gear case mounting screw (M12) 78 to 90 7.9 to 9.2 58 to 66
Front gear case cover mounting screw 48 to 55 4.9 to 5.7 36 to 41
KiSC issued 02, 2017 A

Kubota BX2670 Specifications

General

Transmission	Hydrostatic
Hydraulic System Type	Open center
3-Point Hitch	Category I
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Power Take-off (PTO)	Independent
Rear PTO RPM	540
Mid PTO RPM	2500
Steering	Power Steering
Brakes	Wet disc
Engine Type	Diesel
PTO Horsepower	19.4 hp (14.5 kW)
Fuel Tank Capacity	6.6 gal (25 L)
Hydraulic Pump Capacity	6.3 GPM (23.8 L/min)
Lift Capacity at 24"	680 lbs (308 kg)
Wheelbase	55.1 in (1400 mm)
Horsepower	25.5 hp (19 kW)
