Kubota GL7000 User Manual

7
GL6000, GL7000, GL9000, GL11000, WSM
SPECIFICATIONS
* Conversion Formula : HP = 0.746 kW, PS = 0.7355 kW
W1030469
Model GL7000-USA GL7000-USA-TM GL7000-STD
Generator
Frequency 60 Hz
Rated output 6.5 kW
Maximum output 7.0 kW
Rated voltage 120 / 240 V 110 / 220 V
Rated current 54.2 / 27.1 A 59.1 / 29.5 A
Phrase and wire 1 - 4
Number of poles 2
Power Factor 1
Insulation Stator coil: B Rotor coil: F
Engine
Design Vertical, liquid cooled, 4 cycle, diesel
Model name Z482-E2B-SEC-3
Rated output 8.1 kW
Speed 3600 min
-1
(rpm)
Number of cylinder -
Bore x Stroke
2 -  67 x 68 mm (2 -  2.52 x 2.68 in.)
Displacement 0.479 L (29.23 cu.in.)
Fuel tank capacity 28 L (7.4 U.S.gals)
Crankcase oil capacity 2.2 L (0.58 U.S.gals)
Starting system Electric type 12 V / 0.8 kW
Battery 38B20R 12 V x 28 Ah / 5 Hr
Continuous operating hours (at rated load) 10 hrs
Net weight kg (lbs) 235 kg (518 lbs)
Output
Receptacle L14-30R
L6-30R
L5-30R
5-20RA (GFCI)
5-20RA (GFCI) 5-15R x 2
Terminal – 3P
KiSC issued 05, 2015 A

Kubota GL7000 Specifications

General

Model	GL7000
Category	Portable Generator
Rated Output	6.5 kVA
Standby Output	7.0 kVA
Rated Output (kW)	5.5 kW
Engine	Kubota D902
Fuel Type	Diesel
Starting System	Electric
Noise Level	72 dB(A)
Phase	Single Phase
