Kubota GL7000 User Manual

8
GL6000, GL7000, GL9000, GL11000, WSM
SPECIFICATIONS
* Conversion Formula : HP = 0.746 kW, PS = 0.7355 kW
W1030823
Model GL9000-STD GL9000-AUS
Generator
Frequency 50 Hz
Rated output 8.0 kW
Maximum output 8.8 kW
Rated voltage 220 V 240 V
Rated current 36.4 A 33.3 A
Phrase and wire 1 - 2
Number of poles 2
Power Factor 1
Insulation Stator coil: B Rotor coil: F
Engine
Design Vertical, liquid cooled, 4 cycle, diesel
Model name D722-E2B-SEC-2
Rated output 10.3 kW
Speed 3000 min
-1
(rpm)
Number of cylinder -
Bore x Stroke
3 -  67 x 68 mm (3 -  2.52 x 2.68 in.)
Displacement 0.719 L (48.89 cu.in.)
Fuel tank capacity 28 L (7.4 U.S.gals)
Crankcase oil capacity 3.4 L (0.90 U.S.gals)
Starting system Electric type 12 V / 1.0 kW
Battery 55B24R 12 V x 36 Ah / 5 Hr
Continuous operating hours (at rated load) 8.5 hrs
Net weight kg (lbs) 280 kg (617 lbs)
Output
Receptacle 6-15R  2 15A  3
Ter m ina l 2P –
KiSC issued 05, 2015 A

Kubota GL7000 Specifications

General

Model	GL7000
Category	Portable Generator
Rated Output	6.5 kVA
Standby Output	7.0 kVA
Rated Output (kW)	5.5 kW
Engine	Kubota D902
Fuel Type	Diesel
Starting System	Electric
Noise Level	72 dB(A)
Phase	Single Phase
