Kubota L3540 User Manual

6 SPECIFICATIONS
NOTE : *Manufacturer's estimate
The company reserve the right to change the specifications without notice.
Hydraulic
unit
Hydraulic control system Position control
Pump capacity
L
(U.S.gals)/
min.
31.5 (8.3) 37.0 (9.8) 35.6 (9.4)
Three point hitch SAE category 1
SAE category
1, 2
Max. lift
force
At lift
points
kg (lbs.) 1700 (3750) 1750 (3860)
24 in.
behind
lift
points
kg (lbs.) 1200 (2650) 1250 (2760) 1350 (2980)
System pressure
MPa
(kgf/cm )
17.7 (180)
PTO
Rear PTO
SAE 1-3/8, 6 splines
PTO/
Engine
speed
rpm 540/2550
MID-PTO
(if equipped)
USA No.5 (KUBOTA 10-tooth) involute spline
PTO/
Engine
speed
rpm 2000/2580
Model
L3240 L3540 L3940 L4240 L4740 L5040
4WD

Kubota L3540 Specifications

General

Drive	4WD
Displacement	111.4 cu in (1.8 L)
Hydraulic System Type	Open center
3-Point Hitch Category	Category I
Tire Size (Rear)	12.4-24
Engine Type	Diesel
PTO Power	29.5 hp
Transmission	Hydrostatic
Number of Gears	3-range
Weight	2601 lbs (1180 kg)
Height	91.7 in (232 cm)
Tire Size (Front)	7-16
