Kubota L3540 User Manual

OPERATING THE TRACTOR34
BClutch Pedal
To avoid personal injury:
A Sudden release of the clutch may cause the
tractor to lunge in an unexpected manner.
The clutch is disengaged when the clutch pedal is fully
pressed down.
To help prevent premature clutch wear:
A The clutch pedal must be quickly disengaged and be
slowly engaged.
A Avoid operating the tractor with your foot resting on the
clutch pedal.
A Select proper gear and engine speed depending on
the type of job.
4. Raise the implement.
(See "HYDRAULIC UNIT" section.)
(1) Position control lever (A) "UP"
5. Depress the clutch pedal.
(1) Clutch pedal

Kubota L3540 Specifications

General

Drive	4WD
Displacement	111.4 cu in (1.8 L)
Hydraulic System Type	Open center
3-Point Hitch Category	Category I
Tire Size (Rear)	12.4-24
Engine Type	Diesel
PTO Power	29.5 hp
Transmission	Hydrostatic
Number of Gears	3-range
Weight	2601 lbs (1180 kg)
Height	91.7 in (232 cm)
Tire Size (Front)	7-16
