6-M11
BX1860, BX2360, BX2660, RCK48(P)-18BX, RCK54(P)-23BX, RCK60B-23BX, LA203, LA243, WSM
ELECTRICAL SYSTEM
6. OTHERS
[1] DC OUTLET
DC outlet is equipped to this machine.
The capacity of the DC outlet is 12 V / 120 W.
The electrical device as a CD player, a mobile phone
battery charger can be used to the DC outlet.
The DC outlet (1) consists of the DC outlet body (3)
and the cover (4).
W1021891
(1) DC Outlet
(2) Electrical Device
(3) DC Outlet Body
(4) Cover
RL : Red / Blue Lead
B : Black Lead
To Next Page
