PERIODIC SERVICE132
BChecking Fuel Line
1. Check to see that all lines and hose clamps are tight
and not damaged.
2. If hoses and clamps are found worn or damaged,
replace or repair them at once.
A If the fuel line is removed, be sure to properly bleed the
fuel system.
(See "Bleeding Fuel System" in "SERVICE AS
REQUIRED" in "PERIODIC SERVICE" section.)
BAdjusting Brake Pedal
To avoid personal injury or death:
A Stop the engine and chock the wheels before
checking brake pedal.
A To prevent uneven braking, the specification
must be within the recommended limit. If found
out of the specifications, contact your local
KUBOTA Dealer for adjusting the brakes.
C Checking the brake pedal free travel
1. Set the parking brake.
2. Slightly depress the brake pedals and measure free
travel at the top of pedal stroke.
A Brake pedals should be equal when depressed.
(1) Fuel lines
(2) Clamp bands
(3) Fuel cooler
Proper
brake pedal
free travel
Right brake
pedal
3 to 7 mm on the pedal
Left brake
pedal
Right brake free travel
(actual value) + 9 to11 mm
on the pedal.
Step on the right brake, and the trailer hydraulic brake
allows some pilot oil to flow. This means that the free
travel is different between the left and right brakes.
(1) Brake pedals (A) "FREE TRAVEL"
