3SPECIFICATIONS
Hydraulic
unit
Hydraulic control system Position control
Pump capacity
L (U.S.gals.)
/ min
43.9 (11.6)
Three point hitch Category 1 and 2
Max.
lifting
force
At lifting
points
kg (lbs.)
1900 (4189)
At lower link end with links horizontal
24 in.
behind
lifting
point
kg (lbs.) 1500 (3307)
Remote hydraulic control Max. three remote valves (option)
System pressure
MPa
(kgf/cm )
19.1 (195)
Traction system Swinging drawbar, adjustable in direction
PTO
Live PTO
(Indepen-
dent)
Direction of turning Clockwise, viewed from tractor rear
PTO/
Engine
speed
rpm 6 spline: 540 / 2295
The company reserves the right to change the specifications without notice.
NOTE: *1 Manufacturer's estimate
Model
M7040SU
2WD 4WD
