32 THREE-POINT HITCH & DRAWBAR

THREE-POINT HITCH & DRAWBAR

(1) Top link

(2) Lifting rod (Left)

(3) Telescopic stabilizers

(4) Lower link

(5) Lifting rod (Right)

(6) Drawbar
