3SPECIFICATIONS
A The company reserves the right to change the specifications without notice.
A The values in "Ground clearance" and "Weight" are those of the machine equipped with the tires in the table above.
TRAVELING SPEEDS
Cargo bed
Width mm (in.) 1320 (52)
Length (1 row/2 row) mm (in.) 1360 (53.5) / 860 (33.9)
Depth mm (in.) 290 (11.4)
Volume (1 row/2 row) m (cu.ft.) 0.53 (18.7) / 0.33 (11.7)
Bed height
(unloaded)
mm (in.) 850 (33.5)
Cargo bed capacity
(1 row/2 row)
kg (lbs.) 500 (1102) / 300 (661)
Sound level, operator ear db (A) 85
Tires
Front
25x10-12 HDWS, 6PLY
25x10-12 ATV, 6PLY
25x12-12 Turf, 4PLY
25x10-12 HDWS, 6PLY
25x10-12 ATV, 6PLY
Rear
25x10-12 HDWS, 6PLY
25x11-12 ATV, 6PLY
25x12-12 Turf, 4PLY
25x10-12 HDWS, 6PLY
25x11-12 ATV, 6PLY
Front deluxe guard Std. Std.
Body color Orange Camo
Bed lift Std. Std.
Speedometer Std. Std.
Range gear
shift lever
km/h (mph)
Low 13 (8)
Medium 25 (16)
High 40 (25)
Reverse 16 (10)
Model Worksite/Orange Worksite/Camo
