2 SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model RTV400Ci
Engine
Model SUBARU GH4120
Type 1 cylinder OHC, Air-cooled, EFI Gas
Displacement L (cu. in.) 0.404 (24.7)
Fuel Capacity L (U.S.gals) 20 (5.3)
Transmission Continuously variable transmission (CVT)
Wheels, Drive system 4, Rear 2WD or 4WD
Differential lock Standard; hand operated with mechanical holder
Gear selection Hi-Lo range forward, neutral, reverse
Brakes
Front / Rear Dry disk brake
Parking brake Rear wheel, hand lever
Steering Rack & Pinion
Suspension
Front Independent, MacPherson strut-type
Rear Semi-independent, Multi-link
Dimensions
Length mm (in.) 2690 (105.9)
Width mm (in.) 1390 (54.7)
Height, overall mm (in.) 1829 (72)
Front tread centers mm (in.) 1016 (40)
Rear tread centers mm (in.) 1041 (41)
Wheelbase mm (in.) 1800 (70.9)
Ground
clearance
front axle
mm (in.)
205 (8.1)
rear axle 175 (6.9)
Turning diameter m (ft) 7 (22.9)
Max. rolling weight
(Towing Capacity)
kg (lbs.) Rear: 500 (1102) / Front: 250 (551)
Payload capacity kg (lbs.) 480 (1058)
Weight kg (lbs.) 565 (1246) with ATV Tires / 570 (1257) with HDWS Tires
Cargo bed
Width mm (in.) 1032 (40.6)
Length mm (in.) 856 (33.7)
Depth mm (in.) 290 (11.4)
Volume m (cu.ft.) 0.25 (9)
Bed height
(unloaded)
mm (in.) 810 (31.9)
Max. cargo bed load kg (lbs.) 200 (441)
