54 SPECIFICATIONS
ENGLISH
A Specifications are subject to change without notice.
A Flywheel type is SAE clutch No.11-1/2, SAE clutch No.10 or its equivalent.
A Flywheel housing type is SAE No.3 or its equivalent.
A Governor drop is within 5%.
A Continuous will operate at the stated rating continuously and have a 10% overload capability for one hour in 12
hours.
A Standby will operate at the stated full rating for one hour in 12 hours. No overload capacity is specified for this rating.
Model V3300-E3BG
Type Vertical, water-cooled, 4-cycle diesel engine
Number of cylinders 4
Bore and stroke mm (in.) 98 × 110 (3.86 × 4.33)
Total displacement L(cu.in.) 3.318 (202.49)
Combustion type Spherical type (E-TVCS)
SAE NET Continuous kW / rpm
H.P. (SAEJ1349) (HP / rpm)
28.1/1800 (37.7/1800)
23.0/1500 (30.8/1500)
SAE Standby kW / rpm
H.P. (SAEJ1349) (HP / rpm)
31.0/1800 (41.6/1800)
25.4/1500 (34.1/1500)
Maximum bare speed rpm 1890
Order of firing 1-3-4-2
Direction of rotation Counter-clockwise (viewed from flywheel side)
Injection pump Bosch type mini pump
Injection pressure MPa
(kgf / cm
2
, psi)
13.73 (140, 1991)
Injection timing (Before T.D.C.) 0.17 rad (10°)
Compression ratio 22.6
Fuel Diesel fuel oil No.2-D
Lubricant (API classification) above CF grade
Dimension mm (in.)
(length × width × height)
769 × 536 × 770
(30.28 × 20.10 × 30.31)
Dry weight kg (lbs.) 276 (608)
Starting system Cell starter (with air heater)
Starting motor 12 V, 2.5 kW
Charging generator 12 V, 540 W
Recommended battery capacity 12 V, 88 AH
