G-23
ZD21N-EC, ZD21-EC, ZD28-EC, WSM
G GENERAL
■ Test 6 (OPERATOR ON THE SEAT)
1. Start the engine.
2. Do not set the parking brake.
3. Shift the PTO lever (4) to “DISENGAGE” (OFF) position.
4. Grasp the motion control levers (3) and move then inward from
“NEUTRAL LOCK” position to “NEUTRAL” position and then
release the levers.
5. Stand up. (Do not get off the machine.)
6. The engine must shut off.
■ Test 7 (OPERATOR ON THE SEAT)
1. Start the engine.
2. Do not set the parking brake.
3. Shift the PTO lever (4) to “ENGAGE” (ON) position.
4. Stand up. (Do not get off the machine.)
5. The engine must shut off.
W1032761
(1) Parking Brake Lock Pedal
(2) Parking Brake Release Lever
(3) Motion Control Lever
(4) PTO Lever
(5) Key Switch
To Next Page
