SERIES: KM-O(ST) & KM-T(ST)
Operating and maintenance instructions
PRESSURE + TEMPERATURE LIMITS
BALL VALVES (F1/F27) MADE OF STAINLESS STEEL (1.4408)
BALL SEAT PTFE/25% glass fiber reinforced
1
PTFE/50% stainless steel
2
SIZE RANGE TEMPERATURE
KM-
OXST
O-ring
KM-
TXST
Teflon®
KM-
OXST
O-ring
KM-
TXST
Teflon®
KM-
OXST
O-ring
KM-
TXST
Teflon®
KM-
OXST
O-ring
KM-
TXST
Teflon®
PN 16 PN 40 PN 16 PN 40
-60°C – 40 bar – 40 bar – 40 bar – 40 bar
DN 15 - 50
-25°C
40 bar 40 bar
50°C
40 bar
40 bar
100°C 40 bar 40 bar
125°C
38.15 bar 38.15 bar
150°C 30 bar 30 bar
180°C 22 bar 28 bar
200°C 12 bar 24 bar
220°C – 20 bar
DN 65 - 150
-60°C – 16 bar – 40 bar – 16 bar – 40 bar
-25°C
16 bar 40 bar 16 bar 40 bar
50°C 16 bar 40 bar 16 bar 40 bar
100°C 16 bar 40 bar 16 bar 40 bar
125°C 15.25 bar 38.15 bar 15.25 bar 38.15 bar
150°C
14.5 bar 30 bar 14.5 bar 30 bar
180°C 13.84 bar 20 bar 13.84 bar 25 bar
200°C 10 bar 10 bar 13.4 bar 20.5 bar
220°C
– – 13.12 bar 16 bar
Note:
1
Restriction of temperature data (min/max) due to seat material used, PTFE/25% glass or EN 1092. 14E0
2
Restriction of temperature data (min/max) due to seat material used, PTFE/50% glass or EN 1092. 14E0
DT-KM-STXKH.2018-04-03.R8.EN
Legend:
KM Kugelhahn Müller
O O-ring
T Teflon®
X Stainless steel (1.4408)
ST Standard valve
F1/F27 Face-To-Face dimension
FDA DESIGN · SEAT: PURE PTFE
SIZE RANGE TEMPERATURE
KM-TXST
Teflon®
KM-TXST
Teflon®
PN 16** PN 40*
*DN 15 - 150
-60°C 16 bar 40 bar
125°C 15.25 bar 38.15 bar
**DN 65 - 150
200°C 8 bar 10 bar
Note:
Temperature data (min/max) due to seat material used, pure PTFE or EN 1092. 14E0
