Specifications
Physical Specifications
A-3
Physical Specifications
Electrical Specifications
AC supply: selectable; 100V, 120V, 220V, or 240V. 1.0 amps at 120 volts nominal
Safe Voltage Ranges
If the voltage drops below the minimum safe level at any voltage setting, the K2600 will reset,
but no data will be lost. If the voltage exceeds the maximum safe level, the K2600 may overheat.
Overall dimensions
K2600R K2600 K2600X
Width
16.9 in
1
1. Excluding rack-mount brackets
43.0 cm 47.8 in 121.4 cm 54.3 in 137.9 cm
Depth 13.9 in 35.4 cm 17.8 in 45.1 cm 17.8 in 45.1 cm
Height 5.1 in 13.0 cm 4.8 in 12.2 cm 4.8 in 12.2 cm
Weight 24.65 lb 11.2 kg 55.5 lb 25.2 kg 72.0 lb 32.7 kg
Voltage setting: 100V 120V 220V 240V
Safe voltage range: 85—107 95—125 180—232 190—250
Safe frequency range: 48—65 48—65 48—65 48—65
