A-4
Specifications
Analog Audio Specifications
Analog Audio Specifications
Audio Jacks
¥ 1/4-inch TRS balanced/unbalanced
¥ Tip = Positive
¥ Ring = Negative
¥ Sleeve = Chassis Ground
Separate Outputs
Mix Outputs
Headphone Output
Balanced Unbalanced
Maximum Output 21 dBu 15 dBu
Output Impedance 200
Ω
200
Ω
Balanced Unbalanced
Maximum Output 27 dBu 21 dBu
Output Impedance 200
Ω
200
Ω
Maximum Output 21 dBu
Output Impedance 47
Ω
