4-14
Control Sources
Constant Control Sources
Constant Control Sources
The remaining control sources are constants, which appear only when youÕre assigning control
sources as inputs for the FUNs. Assigning one of these values Þxes the inputÕs control signal
value at a steady level.
Note: There are no control sources that correspond to numeric entries 252Ñ254.
Assigned
Value
Corresponding Constant
Assigned
Value
Corresponding Constant
133 -0.99 201 0.09
134 -0.98 202 0.10
135 -0.97 203 0.12
136-140 -0.96 to -0.92 204 0.14
141 -0.91 205 0.16
142 -0.90 206-210 0.18 to 0.26
143-145 -0.88 to -0.84 211-215 0.28 to 0.36
146-150 -0.82 to -0.74 216-220 0.38 to 0.46
151-155 -0.72 to -0.64 221-225 0.48 to 0.56
156-160 -0.62 to -0.54 226-230 0.58 to 0.66
161-165 -0.52 to -0.44 231-235 0.68 to 0.76
166-170 -0.42 to -0.34 236-240 0.78 to 0.86
171-175 -0.32 to -0.24 241 0.88
176-180 -0.22 to -0.14 242 0.90
181 -0.12 243 0.91
182 -0.10 244 0.92
183 -0.09 245 0.93
184 -0.08 246-250 0.94 to 0.98
185 -0.07 251 0.99
186-190 -0.06 to -0.02 256 OFF
191 -0.01
192 0.00
193 0.01
194 0.02
195 0.03
196-200 0.04 to 0.08
