Tools and Materials Required for Installation
9
Installing in Keyboard Models
Removing the Access Panel
1. Make sure that the PC2 is disconnected from its power
supply, and that you’ve discharged any residual static
electricity by touching a conductive object (like the
metal casing of the PC2 itself).
2. Position the foam pads on your work surface so that
they’ll support the ends of the keyboard.
3. Place the PC2 face-down on the foam pads, with the
keyboard facing away from you. Make sure that the
PC2 is not resting on the Alpha Wheel or sliders.
4. Using a #1 Phillips screwdriver, remove the seven
screws that secure the access panel, as shown in
Figure 1.
Figure 1 Removing the retaining screws
5. Remove the access panel by lifting its far edge and
pulling it up and away from you.
