9
HV™ 30
Specifications
Tubes Preamp 1-12AX7
Output Power 30 Watts, RMS 8Ohms@5%THD
Speakers 1X12Inch Celestion G12P80
Input Impedance Single Input 100 K ohms
Hum & Noise -60 dBV Residual Noise, all level controls 0% (minimum)
Nominal Signal to Noise -70 dBV Rhythm Channel, with Volume half and Master Maximum, Boost on 10
System Gain 30 dBV Rhythm Channel Nominal gain, Volume @ 5
60 dBV Rhythm Channel Maximum gain, Volume @ 10
30 dBV Lead Channel Nominal gain, Volume @ 5
60 dBV Lead Channel Maximum gain, Volume @ 10
6dBV Gain increase at 1 kHz when Crunch/Grind is pressed
6dBV Gain increase at 1 kHz when Fat/Lean is pressed
XLR Direct Output
Digital Effects
Footswitch Jack
Recommended footswitch
USA/Canada 120VAC/60Hz, 60W nominal
Europe 230VAC/50Hz, 60W nominal
UK 230VAC/50Hz, 60W nominal
Australia 240VAC/50Hz, 60W nominal
Japan 100VAC/50-60Hz, 60W nominal
mm/kg 425 (Height) x 459 (Width) x 246 (Depth), 15.4 kg
Inches/Pounds 16 3/4 (Height) x 18 (Width) x 9 5/8 (Depth), 34 lbs
Tip Selects Rhythm/Lead, Ring selects Effects On/Off
24 bit DSP module, 16 effects w/programmable tap-toggle switch.
All measurements taken with 1 KHz
input signal, Tone controls flat,
Effects off. Measured at speaker with
8 ohm load.
Power Requirements
Dimensions/Weight
After power amp with speaker emulation
KAC-FS201 (not included).
