9
HV™ 65
Specifications
Model HV 65 Hybrid Tube Guitar Amplifier
Tubes Preamp 1-12AX7
Output Power 65 W atts, RMS 8 Ohms @ 5% THD
Speakers 1X12Inch Celestion G12P80
Input Impedance Single Input 100 K ohms
Hum & Noise -60 dBV Residual Noise, all level controls 0% (minimum)
System Gain 45 dBV Rhythm Channel Nominal gain, Volume @ 5
65 dBV Rhythm Channel Maximum gain, Volume @ 10
50 dBV Lead Channel Nominal gain, Volume @ 5
70 dBV Lead Channel Maximum gain, Volume @ 10
10 dBV Maximum gain offootswitchable Volume Boost
10 dBV Gain increase at 1 kHz when Gain Boost is pressed
6dBV Gain increase at 1 kHz when Overdrive is pressed
27 ~ 37 dBV Power amp gain (Effects Return to Speaker, depending on Boost)
Nominal Signal to Noise 70 dBV Rhythm Channel, with Volume halfand Master Maximum, Boost on 10
0.33 VRMS (-10 dBV) Levels w/Boost on 10 to reach full power output
1VRMS(0dBV) Levels w/Boost on 0 to reach full power output
Footswitchable Boost Master Volume Boost Adjustable from 0 to +10dB boostAFTER the Effects Loop
XLR Direct Output After power amp with speaker emulation
Digital E ffec ts
Use KACFS101M (sold separately) or standard momentary Footswitch with mono cable for Tap.
USA/Canada 120VAC/60Hz, 120W nominal
Europe 230VAC/50Hz, 120W nominal
UK 230VAC/50Hz, 120W nominal
Australia 240VAC/50Hz, 120W nominal
Japan 100VAC/50-60Hz, 120W nominal
mm/kg 465 (Height) x 535 (Width) x 300 (Depth), 16.8kg
Inches/Pounds 18 (Height) x 21 (Width) x 11 3/4 (Depth), 36.7 lbs
Uses a standard stereo shielded cable, but can use mono cable for emergency limited functions.
Dimensions
Power Requirements
Footswitch
All measurements taken with
1 KHz input signal, Tone
controls flat, Boost volume
control at 0 Unless stated
otherwise, Effects turned off.
Measured at speaker jack
with 8 ohm load.
Effects Loop
Use KACFS301 (sold separately) to Select Rhythm/Lead, Boost, Effects On/Off
24 bit DSP module, 16 effects w/programmable tap-toggle switch.
