Effects 2 Monitor
Effects 2 Main
Effects 2
Chorus
Short Room
Med Room
Small Hall
Med Hall
Chorus/Rev
Chorus/Hall
Short Delay
17
16
15
18
Effects 1
Effects 1Monitor
Effects 1 Main
Up
Down
Small Room
Large Room
Small Hall
Large Hall
Chorus
Chorus/Rev
Slapback
Echo
11
12
13
14
EFFECTS 1
EFFECTS 2
DIGITAL EFFECTS
EFFECTS 1 EFFECTS 2
EFFECTS 1 DOWN Button: EFFECTS 2 DOWN Button:
This button scrolls down through the Digital This button scrolls down through the Digital
Effects sounds. Pressing this button when the Effects sounds. Pressing this button when the
(Echo) effect is lit will result in resetting the (Short Delay) effect is lit will result in resetting the
selected sound to the top (Small Room). selected sound to the top (Short Room).
EFFECTS 2 UP Button:
EFFECTS 1 UP Button:
This bottom scrolls up through the Digital Effects
This button scrolls up through the Digital Effects
sounds. Pressing this button when the (Short
sounds. Pressing this button when the (Small
Room) effect is lit will result in resetting the
Room) effect is lit will result in resetting the
selected sound to the bottom (Short Delay).
selected sound to the bottom (Echo).
EFFECTS 2 MAIN Control:
EFFECTS 1 MAIN Control:
This controls the amount of Effects 2 that is sent to
the MAIN Master Section.
This controls the amount of Effects 1 that is sent to
the MAIN Master Section.
EFFECTS 2 MONITOR Control:
EFFECTS 1 MONITOR Control:
This controls the amount of Effects 2 that is sent to
the MONITOR Master Section.
This controls the amount of Effects 1 that is sent to
the MONITOR Master Section.
6
