MIXER STATUS AND FRONT PANEL JACKS
MIXER STATUS FRONT PANEL JACKS
POWER ON LED: EFFECTS 1 INSERT Jack:
When lit, power is being delivered to the mixer. This ¼” STEREO jack allows an external effect to
be used with your KPM8420. TIP = Effects Send.
CHANNELS ON LED:
Ring = Effects Return.
When lit, the channels will deliver signal to the
EFFECTS 2 INSERT Jack:
master sections.
This ¼” STEREO jack allows an external effect to
PHANTOM POWER LED:
be used with your KPM8420. TIP = Effects Send.
When lit, this LED indicates that Phantom power
Ring = Effects Return.
is being delivered to the XLR jacks.
FOOTSWITCH (MUTE/EFFECTS):
MUTE Button:
This ¼” Stereo jack accesses the Channel Mute
When pressed, this button will MUTE the input
and Effects On/Off Functions. TIP = Effects
channels. This switch is defeated when the
Mute. RING = Channel Mute. Suggested
footswitch jack is used. NOTE: Playback inputs
footswitch = Kustom KAC FS202
will still function when channel mute is on.
