Kuvings M12 - Parts

76
PARTS
Align the red dots
●
on each part and
assemble in the order shown. Once
assembled, turn the drum lid clockwise
to close.
STEP 1
Top-set Assembly
STEP 2
Top-set and body assembly
Place the drum lid on the juicing bowl.
Align the down arrow
▼
on the drum lid
with the OPEN mark on the body and
turn to the CLOSE position.
11. Cleaning Brush 12. Rotating Brush 13. Lid Opener
9. Juicing Screw7. Rotation Wiper 8. Strainer
* The products illustrated in this booklet may vary slightly from the actual product. * The products illustrated in this booklet may vary slightly from the actual product.
10. Pusher
+
+
+
+
+
+
