76
PARTS
2. Drum Lid
3. Juicing Bowl
4. Pulp Cup
7. Juice Cup
5. Smart Cap
6. Base
1. Feeding Tube
+
+
+
Align the red dots
●
on each part and
assemble in the order shown. Once
assembled, turn the drum lid clockwise
to close.
STEP 1
Top-set Assembly
STEP 2
Top-set and base assembly
+
+
Place the drum lid on the juicing bowl.
Align the down arrow
▼
on the drum lid
with the OPEN mark on the base and
turn to the CLOSE position.
Pusher
Align
Align the dots
●
and slide
the pusher in.
Detachable
+
10. Juicing Screw
13. Rotating Brush
9. Strainer8. Rotation Wiper
12. Cleaning Brush
11. Pusher
14. Round Brush
(Optional)
To Next Page
