7
6
PARTS
2. Drum Lid
4. Pulp Cup
3. Juicing Bowl
6. Juice Cup
5. Smart Cap
7. Base
1. Hopper
10. Juicing Screw
9. Strainer
11. Pusher
8. Rotation Wiper
12. Cleaning Brush
Align the red dots
ⷅ
on each part and
assemble in the order shown. Once
assembled, turn the drum lid clockwise to
close.
STEP 1
Top-set Assembly
STEP 2
Top-set and Base Assembly
Detachable
+
+
+
+
+
* The products illustrated/photographed in this booklet may vary slightly from the actual product.
Place the drum lid on the juicing bowl.
Align the down arrow
ⶼ
on the drum lid
with the OPEN mark on the base and
turn to the CLOSE position.
EN
To Next Page
