PARTS
Align the red dots
●
on each part and
assemble in the order shown. Once
assembled, turn the drum lid clockwise
to close.
STEP 1
Top-set Assembly
STEP 2
Top-set and body assembly
Place the assembled top set onto the
body. Align the down arrow
▼
on the
drum lid with the OPEN mark on the
body and turn to the CLOSE position.
11. Cleaning Brush 14. Round Brush
(Optional)
12. Cleaning Tool 13. Lid Opener
17. Smoothie Strainer
(Optional)
9. Juicing Screw7. Rotation Wiper 8. Strainer
* The products illustrated in this booklet may vary slightly from the actual product. * The products illustrated in this booklet may vary slightly from the actual product.
10. Pusher
+
+
+
+
+
+
EN
1. Drum Lid
* Feeding Tube
16.
Coarse
Strainer
(Optional)
15. Blank Strainer
(Optional)
