Connection Diagram - Multiple System Interlock
Multiple laser projectors may be daisy chained and controlled by a single E-STOP Remote. Any
event which enables the Interlock on any laser projector in the daisy chain will trigger the safety
Interlock for all the systems. After the event has been corrected the START button on the E-STOP
Remote must be pressed by the operator to disable the Interlock, After an Emission Delay period
the laser projectors will be ready for use.
Page 8
