TracNet H90 Installation Guide
24
Configure the System
Configure Built-In Wi-Fi Settings
With Wi-Fi enabled, vessel devices can connect to the
BDU via its built-in wireless access point (WAP). At the
third page of the wizard, you can make changes to the
following built-in Wi-Fi settings:
• BUILT-IN WI-FI: Set to “ON” or “OFF”
• SSID (WI-FI NETWORK NAME): Enter a unique name
for the Wi-Fi network
• BAND: Select either 2.4 GHz or 5 GHz
• CHANNEL: Select either Auto or 1-11 channels
• PASSWORD: Change the password (at least 8
characters)
Figure 43: Configuring the Built-in Wi-Fi Settings
When you are done, select Next.
Set the Port Configuration
At the fourth page, you can change the LAN configuration
of the BDU’s Ethernet ports and built-in Wi-Fi, if desired.
Note: For details on the differences between High-speed
and Unlimited Use VSAT data speeds and rates, refer to
the airtime rate sheet. For details on external VoIP devices,
see “External VoIP Devices (Optional)” on page 30
.
Figure 44: Setting the Port Configuration
When you are done, select Next.
IMPORTANT!
Establishing a wireless connection onboard a steel
vessel might require a special external WAP and
advanced networking expertise.
IMPORTANT!
For the customer’s protection, an open Wi-Fi without
security protocols is not permitted. Setting Built-in
Wi-Fi to “On” will simultaneously activate WPA-PSK
security and require creating a Wi-Fi password.
Option Configuration
Split (default) Ports 1-2, Wi-Fi: High-speed LAN
Ports 3-4: Unlimited Use LAN
HS Ports 1-4, Wi-Fi: High-speed LAN
UL Ports 1-4, Wi-Fi: Unlimited Use LAN
HS + VoIP Ports 1-3, Wi-Fi: High-speed LAN
Port 4: External VoIP device
UL + VoIP Ports 1-3, Wi-Fi: Unlimited Use LAN
Port 4: External VoIP device
Split + VoIP Ports 1-2, Wi-Fi: High-speed LAN
Port 3: Unlimited Use LAN
Port 4: External VoIP device
