KWIK GOAL FLEX - Open Front Bases; Add Tension Rods

NZ423 Rev. 02/11/19
Front or Rear
Tension Rod
Bottom
Tension Rod
5. Add tension rods to base as shown.
Open until button is engaged
Left Base
Left Rear Base
4. Open left and right bases by swinging outward until button
locks in place in left and right rear base.
Left Base
Right Base
Left Rear Base
Right Rear Base
Rear Tension Rod
(Short)
Bottom
Tension Rod
Bottom
Tension Rod
Front Tension Rod
(Long)
Front Tension Rod
Rear Tension Rod
Bottom
Tension Rod
Left Base
