Section 5.0 - Controls
Work Safely. Always wear safety glasses near the machine.
NORMAL MODE
• Performs the following homing cycle
• X axis moves left at high speed to limit sensor
• Y axis moves back at high speed to limit sensor
• Z axis moves up at high speed to limit sensor
• X, Y & Z axes change to slow speed
• X axis re-homes and moves to right of the limit sensor
• Y axis re-homes and moves forward of the limit sensor
• Z axis re-homes and moves down from the limit sensor
This establishes and denes the home position of the machine
If machine is powered o󰀨 for any reason it is important to initialize machine by
performing the "home" routine prior to "go to origin" or running production.
NORMAL MODE
• Moves the X, Y & Z axes to the origin position. This position is dened by homing the
machine then jogging the head to the desired position and then choosing "set origin" from
the main menu.
DIAGNOSTIC MODE
• Advances output cursor to next output number
• Toggles between XYZ & RST axes
DISPLAY FIXTURE INFORMATION MODE
• Toggles between the units of the rotary xture diameter value and numerical entry functions.
SELECTING RUN FIXTURE (ROTARY) MODE
• Toggles from unit to unit of rotary xture diameter value
NUMERICAL EDITING
• Toggles curser from unit to unit of a numerical value
NORMAL MODE
• Scrolls upward through the menu
DIAGNOSTIC MODE
• Rotates 4th axis
JOB LOADED MODE
• Displays xture information for Step & Repeat or the diameter value for rotary xture
DISPLAY FIXTURE MODE
• Scrolls value of selected unit up by one for diameter
NUMERICAL EDITING
• Scrolls value of selected unit up by one
SELECTING RUN FIXTURE (ROTARY) MODE
• Scrolls value of selected unit up by one for diameter or numerical entries
SET ROTARY DIRECTION MODE
• Sets rotary axis to clockwise mode
RUN MODE
• Increases speed on the y, in Tool File Mode only
