Section 5.0 - Controls
Work Safely. Always wear safety glasses near the machine.
NORMAL MODE
• Scrolls downward through menu
DIAGNOSTIC MODE
• Rotates 4th axis
JOB LOADED MODE
• Displays all of the lines of text in that job
Plain Text = Alpha-numerics
(Blank) = Serial Number
( .JOB) = Graphic File
Displays line information for any line by pressing Enter.
DISPLAY FIXTURE MODE
• Scrolls value of selected unit down by one for diameter.
NUMERICAL EDITING
• Scrolls value of selected unit down by one.
SELECTING RUN FIXTURE (ROTARY) MODE
• Scrolls value of selected unit down by one for diameter or numerical entries
SET ROTARY DIRECTION MODE
• Sets rotary axis to counter-clockwise mode.
RUN MODE
• Decreases speed on the y, in Tool File Mode only
NORMAL MODE
• Jogs head to left. Time/touch sensitive
FIXTURE INFORMATION MODE
• Changes current position from inches to tenths, hundredths, thousandths, etc.
EDIT TOOL FILE MODE
• Changes to the previous tool number
NORMAL MODE
• Jogs head to back. Time/touch sensitive
EDITING FIXTURE WHILE JOB LOADED
• Jogs R Axis
NORMAL MODE
• Jogs head to right. Time/touch sensitive
FIXTURE INFORMATION MODE
• Changes current position from inches to tenths, hundredths, thousandths, etc.
EDIT TOOL FILE MODE
• Changes to the next tool number
NORMAL MODE
• Jogs head to front. Time/touch sensitive
EDITING FIXTURE WHILE JOB LOADED
• Jogs R Axis
