KWS MS-12A - Technical Parameters

13
TECHNICAL PARAMETERS
Model MS-12A
Rated Voltage AC 110V / 60Hz
Slicing Motor Power 1050W / 1.43 HP
Reciprocating Motor Power 420W / 0.57 HP
Blade Rotational Speed 490 r/min
Slicing Speed 37 times / min
Amps 8.75A
Drive Belt and Chain
Cutting Thickness 0 - 0.6 inch
Best Meat Temperature
17.6 F / -8C
Lowest Meat Temperature
5F / -15C
Packaging Dimension 28” L x 26” W x 32” H
Shipping Weight 179 lbs.
Certification ETL, NSF, FDA
* H= Height W= Width L= Length
Circuit Diagram
Description
PB1 / PB3 – Off Switch
PB2 / PB4 – On Switch
M1 – Blade Motor
M2 – Automatic Motor
T1 / T2 – Temperature Safety Motor
R1 / R2 – Relay
C1 / C2 – Capacitor
F1 / F2 – Cooling Fan
