Proper Riding Method
54
TPMS, Electronic Tire Pressure Sensor
Operation instructions:
TPMS consists of 3 wireless Tire Pressure Sensors (per
unit for two front wheels and rear wheel respectively,
which are installed in the tire valve.) After sensing current
tire pressure, the sensor will transmit such value to the
controller wirelessly. The controller will then transmit the
signal to the meter where it will be displayed through the
meter and indicator in order to inform the driver about the
current tire pressure value.
1. When the KEYLESS Main Switch is set ON, the Tire
Pressure Sensor related Model Symbol on the left side
of Dashboard will light up; if this symbol then goes out
automatically, the tire pressure is normal (as shown in
the Figure).
2. Described as below is the abnormal phenomenon:
3. The owner needs to replenish or release tire pressure if
the reading is too low or too high. Consult the dealer for
assistance if you have any questions.
(Standard tire pressure under normal inflation:
Front Tire 2.35 kgf/cm
2
; Rear Tire 2.70 kgf/cm
2
)
• Do Not remove wireless Tire Pressure Sensor or
Controller, or TPMS function will be lost.
• No re-adjustment of TPMS is required when a new
tire or rim is replaced.
• Re-adjustment of TPMS is required when replacing a
new wireless tire pressure sensor and controller;
please consult a KYMCO dealer.
• When replacing a tire rim, the Tire Pressure Sensor
shall be kept in a correct order to distinguish the front
one and the rear one.
≧ 3.2kgf/cm
2
or < 1.6kgf/cm
2
Rear Tire Pressure
≧
2
2
Tire pressure indicator
symbol
