14.HANDLEBAR/FRONT WHEEL/FRONTBRAKE/
FRONT SHOCK ABSORBER/STEERING STEM
14-20
DINK 50/125
Remove the screw (6) and brake light switch.
INSTALLATION
Install the brake light switch and tighten the
screw to the specified torque.
Torque: 1 N•m (0.1 kgf•m, 0.7 lbf•ft)
Align the pin on the master cylinder holder
with the hole on the handlebar.
Install the front master cylinder and holder
with the “UP” mark facing up.
Install the bolts and tighten the upper bolt
first then tighten the lower bolt to the
specified torque.
Torque: 12 N•m (1.2 kgf•m, 9 lbf•ft)
